mht 50 dataloger
(No Reviews)
The MarMonix MHT-50 provides unbroken audit-trail compliance during vaccine distribution, biopharmaceutical air-freight, and refrigerated perishable shipping by continuously logging critical temperature (±0.5°C) and relative humidity (±3% RH) thresholds across multi-day transit routes without requiring dedicated software.
WhatsApp
Email
Telegram
Description
MarMonix MHT-50 temperature and humidity data logger Overview
The MarMonix MHT-50 is a compact, high-precision, single-use USB temperature and humidity data logger engineered for strict environmental validation during logistics, cold storage, and cleanroom monitoring. Designed for immediate field deployment, it features an IP66 water- and dust-resistant casing, internal precision sensors, and pre-configured or customizable logging intervals ranging from 1 minute up to 24 hours.
Upon reaching the destination, users simply connect the MHT-50 directly to any standard computer USB port. The device automatically generates tamper-evident PDF analytical reports and raw CSV datasets instantly—eliminating software installation friction and accelerating cargo release workflows.
Key Features & Capabilities
- Plug-and-Play USB Interface: Instant automatic PDF and CSV report generation upon connection—no specialized software or driver installation needed.
- Wide Dynamic Range: Measures temperatures from -30 °C to +70 °C (-22 °F to +158 °F) and 0 to 100% RH with ±0.5 °C temperature accuracy and ±3% RH humidity accuracy.
- Tri-Color LED Status Diagnostics:
- Blue LED: Indicates start-delay mode (default 30 min delay for thermal equilibrium).
- Green LED: Confirms active logging within safe predefined thresholds (default: 2°C to 8°C & 20–80% RH).
- Red LED: Instantly flags temperature/humidity excursion alarms.
- Rugged Enclosure: Rated IP66 ingress protection for reliable performance in condensing refrigerated containers and wet environments.
- Ultra-Slim & Lightweight: Pocket-sized form factor (83.5 × 27.7 × 7.5 mm, 16 g) easily inserts into pharmaceutical shippers, insulated thermal boxes, and pallet packages.
MarMonix MHT50 Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor Type | Internal Temperature & Relative Humidity Sensor |
| Temperature Range & Accuracy | -30 °C to +70 °C (-22 °F to +158 °F) ±0.5 °C (-20 °C to +40 °C); ±1.0 °C (other ranges) |
| Humidity Range & Accuracy | 0% to 100% RH ±3% RH (@ 25 °C, 20%–80% RH); ±5% RH (other ranges) |
| Log Duration & Interval | 90 days default (Customizable 7 to 360 days) | Interval: 5 min default (1 min to 24 h customizable) |
| Alarm Presets | Pre-set <2 °C or >8 °C; 20% to 80% RH (Customizable) |
| Data Export | Automatic PDF Report & CSV Data Export via USB |
| Protection Class | IP66 (Dust-tight and protected against powerful water jets) |
| Battery & Life | Internal CR2032 Coin Cell Battery |
| Dimensions & Weight | 83.5 × 27.7 × 7.5 mm | 16 g |
